SAHARA

Stud Type Welding Machine

#
#
Get Quatation

Stud Type Welding Machine


Particulars Stud Type Welding Machine
Model (AMPS) 150A 200A 250A 300A 400A 600A 300A 400A 600A
Input supply (VOLTS) 230/440 230/440 230/440 230/440 230/440 380/440 380/440 380/440 380/440
Phase 1/2 1/2 1/2 1/2 1/2 2 3 3 3
Frequency (Hz) 50 50 50 50 50 50 50 50 50
Welding current range (AMPS) 45-150 50-200 50-250 60-300 60-400 60-600 60-300 60-400 60-600
Insulation class A A A A A A A A A
Open circuit voltage (O.C.V) (VOLTS) 45 50 50 60 60 60 60 60 60
Max,welding current at 60% duty cycle (AMPS) 120 160 200 300 400 600 300 400 600
Welding electrode size min./max. (M.M.) 2/3.15 2/3.15 2.5/3.15 2.5/4 2.5/4 3.15/5 2.5/4 2.5/4 3.15/5
Cooling NATURAL AIR
Approx dimensions in mm (H/L/W) 420 470 510 560 560 700 560 560 560
560 670 700 825 825 925 825 825 825
385 410 435 470 470 530 470 470 470
Approx weight aluminum/copper (KGS) 45/54 55/65 65/78 90/110 110/130 145/165 120/135 140/160 180/205


Light Duty Models

  1. Compact & light weight, Built with latest design
  2. Useful for repair and maintenance works, light production jobs, in farm and small workshops, automobile garage & repairing workshops
  3. Tested under strict quality control measure to give trouble free service for ling period and electricity saving.
  4. Gives highest valued performance against its cost

Heavy Duty Models

  1. Heavy Duty built with latest design
  2. Useful for fast production structural work machine building and fabrication, filling jobs, reclamation of worn-out machine parts, Arc cutting jobs and many type of truly heavy duty applications.
  3. Tested under strict quality control measure to give trouble free services for long period and electricity saving
  4. Gives highest valued performance against its cost.
